UV IR-CUT Protective Window

How to Replace the Camera Protective Window

D21 UV IR-CUT protect window

Technical Parameter

Diameter: 21mm

Type: UV IR-cut window

Thickness: 1.1mm

Flatness: 1/4 λ

Match Model

ASI120MC-S, ASI178MC.

D25 UV IR-CUT protect window

Technical Parameter

Diameter: 25mm

Type: UV IR-cut window

Thickness: 1.1mm

Flatness: 1/4 λ

Match Model

It is used for ASI174MM, ASI174MC, ASI174MM-COOL, ASI174MC-COOL to protect the sensor from dust and humidity.

D60 UV IR-CUT protect window

Technical Parameter

Diameter: 60mm

Type: UV IR-cut window

Thickness: 2mm

Flatness: 1/4 λ

Match Model

It is used for ASI6200MC Pro, ASI2400MC Pro, ASI2600MC Pro/Duo to protect the sensor from dust and humidity.

AR Protective Window

D21 AR protect window

Technical Parameter

Diameter: 21mm

Type: AR window

Thickness: 1.1mm

Flatness: 1/4 λ

Protect the sensor from dust and humidity.

Match Model

ASI120 series, ASI178 series, ASI290 series, ASI224MC series, ASI385 series, ASI185MC series, ASI220 series, ASI462 series, ASI662 series, ASI678 series, ASI664 series, ASI715 series.

D25 AR protect window

Technical Parameter

Diameter: 25mm

Type: AR window

Thickness: 1.1mm

Flatness: 1/4 λ

Match Model

ASI174 series.

Protect the sensor from dust and humidity.

D32 AR protect window

Technical Parameter

Diameter: 32mm

Type: AR window

Thickness: 2mm

Flatness: 1/4 λ

Match Model

ASI1600 series, ASI294 series, ASI183 series, ASI990 series, ASI991 series, ASI585 series(Air not included), ASI533 series, ASI294 series.

D60 AR protect window

Technical Parameter

Diameter: 60mm

Type: AR window

Thickness: 2mm

Flatness: 1/4 λ

Match Model

ASI071 MC Pro, ASI6200MM Pro, ASI2600MM Pro/Duo.
